8A3xxxx Family Programming Guide
STATUS.DPLL7_FILTER_STATUS
DPLL 7 loop filter status.
STATUS.DPLL_SYS_FILTER_STATUS
Loop filter status of system DPLL .
Table 74: STATUS.DPLL7_FILTER_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL7_FILTER_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
07Ch FILTER_STATUS[7:0]
07Dh FILTER_STATUS[15:8]
07Eh FILTER_STATUS[23:16]
07Fh FILTER_STATUS[31:24]
080h FILTER_STATUS[39:32]
081h FILTER_STATUS[47:40]
STATUS.DPLL7_FILTER_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
FILTER_STATUS[47:0] R/O 0 DPLL loop filter status.
Fine phase measurement in units of 50/128 picoseconds.
Table 75: STATUS.DPLL_SYS_FILTER_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL_SYS_FILTER_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
084h FILTER_STATUS[7:0]
085h FILTER_STATUS[15:8]
086h FILTER_STATUS[23:16]
087h FILTER_STATUS[31:24]
088h FILTER_STATUS[39:32]
089h FILTER_STATUS[47:40]
STATUS.DPLL_SYS_FILTER_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
FILTER_STATUS[47:0] R/O 0 System DPLL loop filter status.
Fine phase measurement in units of 50/128 picoseconds.
