8A3xxxx Family Programming Guide
SCRATCH.SCRATCH2
User read or write data. The HW reset value will be restored on soft reset.
SCRATCH.SCRATCH3
User read or write data. The HW reset value will be restored on soft reset.
SCRATCH.SCRATCH1 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
SCRATCH1[31:0] R/W 0 User data.
Table 388: SCRATCH.SCRATCH2 Bit Field Locations and Descriptions
Offset
Address
(Hex)
SCRATCH.SCRATCH2 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
008h SCRATCH2[7:0]
009h SCRATCH2[15:8]
00Ah SCRATCH2[23:16]
00Bh SCRATCH2[31:24]
SCRATCH.SCRATCH2 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
SCRATCH2[31:0] R/W 0 User data.
Table 389: SCRATCH.SCRATCH3 Bit Field Locations and Descriptions
Offset
Address
(Hex)
SCRATCH.SCRATCH3 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
00Ch SCRATCH3[7:0]
00Dh SCRATCH3[15:8]
00Eh SCRATCH3[23:16]
00Fh SCRATCH3[31:24]
SCRATCH.SCRATCH3 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
SCRATCH3[31:0] R/W 0 User data.
