IDT 8A3 Series - STATUS.DPLL3_PHASE_PULL_IN_STATUS; STATUS.DPLL4_PHASE_PULL_IN_STATUS

97©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
STATUS.DPLL3_PHASE_PULL_IN_STATUS
DPLL3 phase pull-in status
STATUS.DPLL4_PHASE_PULL_IN_STATUS
DPLL4 phase pull-in status
STATUS.DPLL2_PHASE_PULL_IN_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
REMAINING_TIME[7:0] R/O 0 Unsigned 8-bit phase pull-in time to finish in seconds.
If the value of this field < 255, the actual remaining time is between
(remaining_time) and (remaining_time + 1) seconds. If the value = 255, it
implies the actual remaining time >= 255 seconds.
Table 114: STATUS.DPLL3_PHASE_PULL_IN_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL3_PHASE_PULL_IN_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
11Fh REMAINING_TIME[7:0]
STATUS.DPLL3_PHASE_PULL_IN_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
REMAINING_TIME[7:0] R/O 0 Unsigned 8-bit phase pull-in time to finish in seconds.
If the value of this field < 255, the actual remaining time is between
(remaining_time) and (remaining_time + 1) seconds. If the value = 255, it
implies the actual remaining time >= 255 seconds.
Table 115: STATUS.DPLL4_PHASE_PULL_IN_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL4_PHASE_PULL_IN_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
120h REMAINING_TIME[7:0]
STATUS.DPLL4_PHASE_PULL_IN_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
REMAINING_TIME[7:0] R/O 0 Unsigned 8-bit phase pull-in time to finish in seconds.
If the value of this field < 255, the actual remaining time is between
(remaining_time) and (remaining_time + 1) seconds. If the value = 255, it
implies the actual remaining time >= 255 seconds.
