23©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
Module: GENERAL_STATUS
Notification for hardware status.
Table 11: GENERAL_STATUS Register Index
Offset
(Hex)
Register Module Base Address: C014h
Individual Register Name Register Description
000h RESERVED This register must not be modified from the read value
001h RESERVED This register must not be modified from the read value
002h RESERVED This register must not be modified from the read value
003h RESERVED This register must not be modified from the read value
004h GENERAL_STATUS.OTP_STATUS Current status of OTP.
008h GENERAL_STATUS.EEPROM_STATUS Current status of EEPROM.
00Ah RESERVED This register must not be modified from the read value
00Bh RESERVED This register must not be modified from the read value
00Ch RESERVED This register must not be modified from the read value
00Dh RESERVED This register must not be modified from the read value
00Eh RESERVED This register must not be modified from the read value
00Fh RESERVED This register must not be modified from the read value
010h GENERAL_STATUS.MAJ_REL Major release number.
011h GENERAL_STATUS.MIN_REL Minor release number.
012h GENERAL_STATUS.HOTFIX_REL Hotfix release number.
014h RESERVED This register must not be modified from the read value
015h RESERVED This register must not be modified from the read value
016h RESERVED This register must not be modified from the read value
017h RESERVED This register must not be modified from the read value
018h RESERVED This register must not be modified from the read value
019h RESERVED This register must not be modified from the read value
01Ah RESERVED This register must not be modified from the read value
01Bh RESERVED This register must not be modified from the read value
01Ch GENERAL_STATUS.JTAG_DEVICE_ID JTAG device identity.
01Eh GENERAL_STATUS.PRODUCT_ID Product identity.
020h GENERAL_STATUS.TEMPERATURE Device internal temperature in degrees Celsius.
022h GENERAL_STATUS.OTP_SCSR_CONFIG_SE
LECT
Selected soft CSR configuration loaded from OTP.
