299©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
BYTE.OTP_EEPROM_PWM_BUFF_10
-
BYTE.OTP_EEPROM_PWM_BUFF_11
-
BYTE.OTP_EEPROM_PWM_BUFF_12
-
Table 410: BYTE.OTP_EEPROM_PWM_BUFF_10 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_10 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
00Ah DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_10 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 411: BYTE.OTP_EEPROM_PWM_BUFF_11 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_11 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
00Bh DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_11 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 412: BYTE.OTP_EEPROM_PWM_BUFF_12 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_12 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
00Ch DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_12 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
