8A3xxxx Family Programming Guide
STATUS.DPLL3_FILTER_STATUS
DPLL 3 loop filter status.
STATUS.DPLL4_FILTER_STATUS
DPLL 4 loop filter status.
Table 70: STATUS.DPLL3_FILTER_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL3_FILTER_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
05Ch FILTER_STATUS[7:0]
05Dh FILTER_STATUS[15:8]
05Eh FILTER_STATUS[23:16]
05Fh FILTER_STATUS[31:24]
060h FILTER_STATUS[39:32]
061h FILTER_STATUS[47:40]
STATUS.DPLL3_FILTER_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
FILTER_STATUS[47:0] R/O 0 DPLL loop filter status.
Fine phase measurement in units of 50/128 picoseconds.
Table 71: STATUS.DPLL4_FILTER_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL4_FILTER_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
064h FILTER_STATUS[7:0]
065h FILTER_STATUS[15:8]
066h FILTER_STATUS[23:16]
067h FILTER_STATUS[31:24]
068h FILTER_STATUS[39:32]
069h FILTER_STATUS[47:40]
STATUS.DPLL4_FILTER_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
FILTER_STATUS[47:0] R/O 0 DPLL loop filter status.
Fine phase measurement in units of 50/128 picoseconds.
