8A3xxxx Family Programming Guide
STATUS.DPLL1_STATUS
DPLL 1 status.
STATUS.DPLL0_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
RESERVED N/A - This field must not be modified from the read value
DPLL0_HOLDOVER_STAT
E_CHANGE_STICKY[5]
R/O 0 Holdover state change sticky bit.
Indicates whether any transition to or from Holdover state occurred.
0 = no transition to or from Holdover state
1 = transition to or from Holdover state
DPLL0_LOCK_STATE_CH
ANGE_STICKY[4]
R/O 0 Lock state change sticky bit.
Indicates whether any transition to or from Locked state occurred.
0 = no transition to or from Locked state
1 = transition to or from Locked state
DPLL0_STATE[3:0] R/O 0 Current state of DPLL0.
0 = freerun
1 = lockacq
2 = lockrec
3 = locked
4 = holdover
5 = open loop
Table 49: STATUS.DPLL1_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL1_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
019h RESERVED[7:6] DPLL1_HOL
DOVER_STA
TE_CHANG
E_STICKY[5]
DPLL1_LOC
K_STATE_C
HANGE_STI
CKY[4]
DPLL1_STATE[3:0]
STATUS.DPLL1_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
RESERVED N/A - This field must not be modified from the read value
DPLL1_HOLDOVER_STAT
E_CHANGE_STICKY[5]
R/O 0 Holdover state change sticky bit.
Indicates whether any transition to or from Holdover state occurred.
0 = no transition to or from Holdover state
1 = transition to or from Holdover state
