IDT 8A3 Series - STATUS.USER_GPIO0_TO_7_STATUS

75©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
STATUS.USER_GPIO0_TO_7_STATUS
GPIO 0 - 7 level status.
Table 76: STATUS.USER_GPIO0_TO_7_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.USER_GPIO0_TO_7_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
08Ah GPIO7_LEV
EL[7]
GPIO6_LEV
EL[6]
GPIO5_LEV
EL[5]
GPIO4_LEV
EL[4]
GPIO3_LEV
EL[3]
GPIO2_LEV
EL[2]
GPIO1_LEV
EL[1]
GPIO0_LEV
EL[0]
STATUS.USER_GPIO0_TO_7_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
GPIO7_LEVEL[7] R/O 0 Level of GPIO pin 7.
0 = low
1 = high
GPIO6_LEVEL[6] R/O 0 Level of GPIO pin 6.
0 = low
1 = high
GPIO5_LEVEL[5] R/O 0 Level of GPIO pin 5.
0 = low
1 = high
GPIO4_LEVEL[4] R/O 0 Level of GPIO pin 4.
0 = low
1 = high
GPIO3_LEVEL[3] R/O 0 Level of GPIO pin 3.
0 = low
1 = high
GPIO2_LEVEL[2] R/O 0 Level of GPIO pin 2.
0 = low
1 = high
GPIO1_LEVEL[1] R/O 0 Level of GPIO pin 1.
0 = low
1 = high
GPIO0_LEVEL[0] R/O 0 Level of GPIO pin 0.
0 = low
1 = high
