8A3xxxx Family Programming Guide
STATUS.DPLL0_PHASE_PULL_IN_STATUS
DPLL0 phase pull-in status
STATUS.DPLL1_PHASE_PULL_IN_STATUS
DPLL1 phase pull-in status
STATUS.DPLL2_PHASE_PULL_IN_STATUS
DPLL2 phase pull-in status
Table 111: STATUS.DPLL0_PHASE_PULL_IN_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL0_PHASE_PULL_IN_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
11Ch REMAINING_TIME[7:0]
STATUS.DPLL0_PHASE_PULL_IN_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
REMAINING_TIME[7:0] R/O 0 Unsigned 8-bit phase pull-in time to finish in seconds.
If the value of this field < 255, the actual remaining time is between
(remaining_time) and (remaining_time + 1) seconds. If the value = 255, it
implies the actual remaining time >= 255 seconds.
Table 112: STATUS.DPLL1_PHASE_PULL_IN_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL1_PHASE_PULL_IN_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
11Dh REMAINING_TIME[7:0]
STATUS.DPLL1_PHASE_PULL_IN_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
REMAINING_TIME[7:0] R/O 0 Unsigned 8-bit phase pull-in time to finish in seconds.
If the value of this field < 255, the actual remaining time is between
(remaining_time) and (remaining_time + 1) seconds. If the value = 255, it
implies the actual remaining time >= 255 seconds.
Table 113: STATUS.DPLL2_PHASE_PULL_IN_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL2_PHASE_PULL_IN_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
11Eh REMAINING_TIME[7:0]
