262©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
PWM_DECODER_0.PWM_DECODER_ID
Unique identifier defined by user.
PWM_DECODER_0.PWM_DECODER_SIGNATURE_0
Select signature symbols to be received in PWM signature mode. Same signature must be applied at both encoder and decoder.
PWM_DECODER_0.PWM_DECODER_CNFG Bit Field Descriptions
Bit Field Name Field Type Default Value Description
GENERATE_PPS[15] R/W 0 Generate PPS pulse.
0 = do not generate internal PPS
1 = generate internal PPS
PPS_RATE[14:0] R/W 0 PWM PPS rate in units of 0.5 Hz.
Table 346: PWM_DECODER_0.PWM_DECODER_ID Bit Field Locations and Descriptions
Offset
Address
(Hex)
PWM_DECODER_0.PWM_DECODER_ID Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
002h DECODER_ID[7:0]
PWM_DECODER_0.PWM_DECODER_ID Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DECODER_ID[7:0] R/W 0 Unique PWM decoder ID in the PWM network.
0xFF should not be used because it is reserved for broadcast.
Table 347: PWM_DECODER_0.PWM_DECODER_SIGNATURE_0 Bit Field Locations and Descriptions
Offset
Address
(Hex)
PWM_DECODER_0.PWM_DECODER_SIGNATURE_0 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
003h FIFTH_SYMBOL[7:6] SIXTH_SYMBOL[5:4] SEVENTH_SYMBOL[3:2] EIGHTH_SYMBOL[1:0]
