GENERAL_STATUS.TEMPERATURE
2s complement signed 16-bit numerical value in degrees Celsius.
GENERAL_STATUS.OTP_SCSR_CONFIG_SELECT
The index of the soft CSR configuration loaded from OTP.
GENERAL_STATUS.PRODUCT_ID Bit Field Descriptions
Bit Field Name Field Type Default Value Description
PRODUCT_ID[15:0] R/O 0 16-bit Product ID code for this specific device, please refer to the Programming
Guide Addendum for the specific device for expected value here.
Table 19: GENERAL_STATUS.TEMPERATURE Bit Field Locations and Descriptions
Offset
Address
(Hex)
GENERAL_STATUS.TEMPERATURE Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
020h TEMP_CELSIUS[7:0]
021h TEMP_CELSIUS[15:8]
GENERAL_STATUS.TEMPERATURE Bit Field Descriptions
Bit Field Name Field Type Default Value Description
TEMP_CELSIUS[15:0] R/O 0 Device temperature as measured by the device's internal temperature sensor.
2s complement number in degrees Celsius.
Table 20: GENERAL_STATUS.OTP_SCSR_CONFIG_SELECT Bit Field Locations and Descriptions
Offset
Address
(Hex)
GENERAL_STATUS.OTP_SCSR_CONFIG_SELECT Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
022h OTP_SCSR_CONFIG_SELECTION[7:0]
GENERAL_STATUS.OTP_SCSR_CONFIG_SELECT Bit Field Descriptions
Bit Field Name Field Type Default Value Description
OTP_SCSR_CONFIG_SE
LECTION[7:0]
R/O 0 Index of OTP SCSR configuration currently selected via startup GPIO function.
