8A3xxxx Family Programming Guide
BYTE.OTP_EEPROM_PWM_BUFF_73
-
BYTE.OTP_EEPROM_PWM_BUFF_74
-
BYTE.OTP_EEPROM_PWM_BUFF_75
-
Table 473: BYTE.OTP_EEPROM_PWM_BUFF_73 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_73 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
049h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_73 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 474: BYTE.OTP_EEPROM_PWM_BUFF_74 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_74 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
04Ah DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_74 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 475: BYTE.OTP_EEPROM_PWM_BUFF_75 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_75 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
04Bh DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_75 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
