8A3xxxx Family Programming Guide
STATUS.IN0_MON_FREQ_STATUS
Input 0 reference monitor frequency status and unit.
STATUS.IN1_MON_FREQ_STATUS
Input 1 reference monitor frequency status and unit.
Table 78: STATUS.IN0_MON_FREQ_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.IN0_MON_FREQ_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
08Ch FFO[7:0]
08Dh FFO_UNIT[15:14] FFO[13:8]
STATUS.IN0_MON_FREQ_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
FFO_UNIT[15:14] R/O 0 Input clock FFO unit enumeration.
0 = 1 ppb
1 = 10 ppb
2 = 100 ppb
3 = 1 ppm
FFO[13:0] R/O 0 Signed 14-bit input clock fractional frequency offset.
Table 79: STATUS.IN1_MON_FREQ_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.IN1_MON_FREQ_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
08Eh FFO[7:0]
08Fh FFO_UNIT[15:14] FFO[13:8]
STATUS.IN1_MON_FREQ_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
FFO_UNIT[15:14] R/O 0 Input clock FFO unit enumeration.
0 = 1 ppb
1 = 10 ppb
2 = 100 ppb
3 = 1 ppm
FFO[13:0] R/O 0 Signed 14-bit input clock fractional frequency offset.
