BYTE.OTP_EEPROM_PWM_BUFF_79
-
BYTE.OTP_EEPROM_PWM_BUFF_80
-
BYTE.OTP_EEPROM_PWM_BUFF_81
-
Table 479: BYTE.OTP_EEPROM_PWM_BUFF_79 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_79 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
04Fh DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_79 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 480: BYTE.OTP_EEPROM_PWM_BUFF_80 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_80 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
050h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_80 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 481: BYTE.OTP_EEPROM_PWM_BUFF_81 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_81 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
051h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_81 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
