8A3xxxx Family Programming Guide
Register Table Overview
When programming an 8A3xxxx family device, it is necessary to read or write values to one or more ‘bit-fields’ within the device. A bit-field
provides status and/or control information on a single aspect of a single feature. A bit field may be as small as a single-bit or many bytes in
length. A bit-field should be treated as an indivisible entity and all bytes of each bit-field should be read or written in a single serial port burst.
Access to bit-fields is performed using byte-oriented addressing. A bit-field may take up multiple byte address and/or multiple bit-fields may
occupy a single byte. When there are multiple bit-fields within a single byte, all bit fields are read from or written to during an access to that
byte address over the serial port. When a bit-field spans multiple byte addresses, all bytes should be read or written in the same serial port
burst transaction to ensure consistency. For bit-fields spanning multiple bytes, the least-significant bits of that bit-field are contained in the byte
with the lowest address.
Bit-fields are grouped into registers and registers are in turn grouped into modules. In the documentation that follows, bit-fields are shown
mapped into register bytes in a table called a Bit-Field Location table. The function of each bit-field is shown in an associated Bit-Field
Description table. One or more bit-fields are grouped into a register. Registers show an address offset for each byte within that register.
