331©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
BYTE.OTP_EEPROM_PWM_BUFF_106
-
BYTE.OTP_EEPROM_PWM_BUFF_107
-
BYTE.OTP_EEPROM_PWM_BUFF_108
-
Table 506: BYTE.OTP_EEPROM_PWM_BUFF_106 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_106 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
06Ah DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_106 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 507: BYTE.OTP_EEPROM_PWM_BUFF_107 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_107 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
06Bh DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_107 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 508: BYTE.OTP_EEPROM_PWM_BUFF_108 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_108 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
06Ch DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_108 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
