8A3xxxx Family Programming Guide
STATUS.IN15_MON_STATUS
Input 15 reference monitor status.
STATUS.IN14_MON_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
IN14_FREQ_OFFS_LIM_S
TICKY[6]
R/O 0 Frequency offset limit sticky bit.
Indicates that frequency offset limit was exceeded for input 14.
0 = no change
1 = live status changed
IN14_NO_ACTIVITY_STIC
KY[5]
R/O 0 No activity sticky bit.
Indicates that no activity was detected for input 14.
0 = no change
1 = live status changed
IN14_LOS_STICKY[4] R/O 0 LOS sticky bit.
Indicates that loss of signal was detected for input 14.
0 = no change
1 = live status changed
RESERVED N/A - This field must not be modified from the read value
IN14_FREQ_OFFS_LIM_L
IVE[2]
R/O 0 Frequency offset limit live status.
Indicates that the current frequency offset exceeds the limit for input 14.
0 = inactive
1 = active
IN14_NO_ACTIVITY_LIVE
[1]
R/O 0 No activity live status.
Indicates no activity on input 14.
0 = inactive
1 = active
IN14_LOS_LIVE[0] R/O 0 LOS live status.
Indicates loss of signal on input 14.
0 = inactive
1 = active
Table 47: STATUS.IN15_MON_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.IN15_MON_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
017h RESERVED[
7]
IN15_FREQ_
OFFS_LIM_
STICKY[6]
IN15_NO_A
CTIVITY_STI
CKY[5]
IN15_LOS_S
TICKY[4]
RESERVED[
3]
IN15_FREQ_
OFFS_LIM_L
IVE[2]
IN15_NO_A
CTIVITY_LIV
E[1]
IN15_LOS_LI
VE[0]
