337©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
BYTE.OTP_EEPROM_PWM_BUFF_124
-
BYTE.OTP_EEPROM_PWM_BUFF_125
-
BYTE.OTP_EEPROM_PWM_BUFF_126
-
Table 524: BYTE.OTP_EEPROM_PWM_BUFF_124 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_124 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
07Ch DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_124 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 525: BYTE.OTP_EEPROM_PWM_BUFF_125 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_125 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
07Dh DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_125 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 526: BYTE.OTP_EEPROM_PWM_BUFF_126 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_126 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
07Eh DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_126 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
