8A3xxxx Family Programming Guide
SERIAL.SER0
Slave serial interface 0 (main serial port) configuration.
SERIAL.SER0_SPI
SPI configuration for serial interface 0 (main serial port).
Table 331: SERIAL.SER0 Bit Field Locations and Descriptions
Offset
Address
(Hex)
SERIAL.SER0 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
002h RESERVED[7:3] ADDRESS_S
IZE[2]
MODE[1:0]
SERIAL.SER0 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
RESERVED N/A - This field must not be modified from the read value
ADDRESS_SIZE[2] R/W 0 Serial interface 0 address size.
0 = 1-byte
1 = 2-byte
MODE[1:0] R/W 0 Serial interface 0 mode.
Set MODE = 0 to maintain current configuration (e.g. mode indicated by
SER0_STATUS_MODE field will remain the same).
0 = no change
1 = I2C
2 = SPI
3 = disabled
Table 332: SERIAL.SER0_SPI Bit Field Locations and Descriptions
Offset
Address
(Hex)
SERIAL.SER0_SPI Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
003h RESERVED[7:5] SPI_SDO_D
ELAY[4]
SPI_CLOCK
_SELECTIO
N[3]
SPI_DUPLE
X_MODE[2]
RESERVED[1:0]
SERIAL.SER0_SPI Bit Field Descriptions
Bit Field Name Field Type Default Value Description
SPI_SDO_DELAY[4] R/W 0 SPI delay SDO driving edge.
0 = driving edge used for SDO
1 = SDO driving edge delayed half-cycle of SCLK
SPI_CLOCK_SELECTION[
3]
R/W 0 SPI Clock Selection for SDI sampling.
0 = rising edge
1 = falling edge
