IDT 8A3 Series - GENERAL_STATUS.HOTFIX_REL; GENERAL_STATUS.JTAG_DEVICE_ID; GENERAL_STATUS.PRODUCT_ID

27©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
GENERAL_STATUS.HOTFIX_REL
Hotfix release number. e.g.. 1.2.Z
GENERAL_STATUS.JTAG_DEVICE_ID
16-bit subset of JTAG ID as determined by BOND_ID.
GENERAL_STATUS.PRODUCT_ID
16-bit numeric value that correlates to the part number.
Table 16: GENERAL_STATUS.HOTFIX_REL Bit Field Locations and Descriptions
Offset
Address
(Hex)
GENERAL_STATUS.HOTFIX_REL Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
012h HOTFIX[7:0]
GENERAL_STATUS.HOTFIX_REL Bit Field Descriptions
Bit Field Name Field Type Default Value Description
HOTFIX[7:0] R/O 0 Hotfix release number. e.g.. 1.2.Z
Table 17: GENERAL_STATUS.JTAG_DEVICE_ID Bit Field Locations and Descriptions
Offset
Address
(Hex)
GENERAL_STATUS.JTAG_DEVICE_ID Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
01Ch JTAG_DEVICE_ID[7:0]
01Dh JTAG_DEVICE_ID[15:8]
GENERAL_STATUS.JTAG_DEVICE_ID Bit Field Descriptions
Bit Field Name Field Type Default Value Description
JTAG_DEVICE_ID[15:0] R/O 0 16-bit ID code for this specific device, please refer to the Programming Guide
Addendum for the specific device for expected value here.
Table 18: GENERAL_STATUS.PRODUCT_ID Bit Field Locations and Descriptions
Offset
Address
(Hex)
GENERAL_STATUS.PRODUCT_ID Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
01Eh PRODUCT_ID[7:0]
01Fh PRODUCT_ID[15:8]
