8A3xxxx Family Programming Guide
GENERAL_STATUS.EEPROM_CONFIG_STATUS
Status of configuration loaded from EEPROM.
Module: STATUS
Live status of alarms and events.
Table 23: GENERAL_STATUS.EEPROM_CONFIG_STATUS Bit Field Locations and Descriptions
Offset
Address
(Hex)
GENERAL_STATUS.EEPROM_CONFIG_STATUS Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
026h EEPROM_CONFIG_STATUS[7:0]
GENERAL_STATUS.EEPROM_CONFIG_STATUS Bit Field Descriptions
Bit Field Name Field Type Default Value Description
EEPROM_CONFIG_STAT
US[7:0]
R/O 0 Status code.
0x0 = success
0x1 = not found
0x2 = incomplete
0x3 = wrong offset
0x4 = wrong length
0x5 = SCSR out of range
0x6 = CRC error
0xA = corrupt header
0xB = EEPROM out of range
Table 24: STATUS Register Index
Offset
(Hex)
Register Module Base Address: C03Ch
Individual Register Name Register Description
000h STATUS.I2CM_STATUS I2C master status.
001h RESERVED This register must not be modified from the read value
002h STATUS.SER0_STATUS Status of serial interface 0.
003h STATUS.SER0_SPI_STATUS Status of serial interface 0 SPI.
004h STATUS.SER0_I2C_STATUS Status of serial interface 0 I2C.
005h STATUS.SER1_STATUS Status of serial interface 1.
006h STATUS.SER1_SPI_STATUS Status of serial interface 1 SPI.
007h STATUS.SER1_I2C_STATUS Status of serial interface 1 I2C.
008h STATUS.IN0_MON_STATUS Input 0 reference monitor status.
009h STATUS.IN1_MON_STATUS Input 1 reference monitor status.
00Ah STATUS.IN2_MON_STATUS Input 2 reference monitor status.
00Bh STATUS.IN3_MON_STATUS Input 3 reference monitor status.
