8A3xxxx Family Programming Guide
00Ch STATUS.IN4_MON_STATUS Input 4 reference monitor status.
00Dh STATUS.IN5_MON_STATUS Input 5 reference monitor status.
00Eh STATUS.IN6_MON_STATUS Input 6 reference monitor status.
00Fh STATUS.IN7_MON_STATUS Input 7 reference monitor status.
010h STATUS.IN8_MON_STATUS Input 8 reference monitor status.
011h STATUS.IN9_MON_STATUS Input 9 reference monitor status.
012h STATUS.IN10_MON_STATUS Input 10 reference monitor status.
013h STATUS.IN11_MON_STATUS Input 11 reference monitor status.
014h STATUS.IN12_MON_STATUS Input 12 reference monitor status.
015h STATUS.IN13_MON_STATUS Input 13 reference monitor status.
016h STATUS.IN14_MON_STATUS Input 14 reference monitor status.
017h STATUS.IN15_MON_STATUS Input 15 reference monitor status.
018h STATUS.DPLL0_STATUS DPLL 0 status.
019h STATUS.DPLL1_STATUS DPLL 1 status.
01Ah STATUS.DPLL2_STATUS DPLL 2 status.
01Bh STATUS.DPLL3_STATUS DPLL 3 status.
01Ch STATUS.DPLL4_STATUS DPLL 4 status.
01Dh STATUS.DPLL5_STATUS DPLL 5 status.
01Eh STATUS.DPLL6_STATUS DPLL 6 status.
01Fh STATUS.DPLL7_STATUS DPLL 7 status.
020h STATUS.DPLL_SYS_STATUS System DPLL status.
021h STATUS.SYS_APLL_STATUS System APLL status.
022h STATUS.DPLL0_REF_STAT DPLL 0 input reference status.
023h STATUS.DPLL1_REF_STAT DPLL 1 input reference status.
024h STATUS.DPLL2_REF_STAT DPLL 2 input reference status.
025h STATUS.DPLL3_REF_STAT DPLL 3 input reference status.
026h STATUS.DPLL4_REF_STAT DPLL 4 input reference status.
027h STATUS.DPLL5_REF_STAT DPLL 5 input reference status.
028h STATUS.DPLL6_REF_STAT DPLL 6 input reference status.
029h STATUS.DPLL7_REF_STAT DPLL 7 input reference status.
02Ah STATUS.DPLL_SYS_REF_STAT System DPLL input reference status.
044h STATUS.DPLL0_FILTER_STATUS DPLL 0 loop filter status.
Table 24: STATUS Register Index
Offset
(Hex)
Register Module Base Address: C03Ch
Individual Register Name Register Description
