32©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
04Ch STATUS.DPLL1_FILTER_STATUS DPLL 1 loop filter status.
054h STATUS.DPLL2_FILTER_STATUS DPLL 2 loop filter status.
05Ch STATUS.DPLL3_FILTER_STATUS DPLL 3 loop filter status.
064h STATUS.DPLL4_FILTER_STATUS DPLL 4 loop filter status.
06Ch STATUS.DPLL5_FILTER_STATUS DPLL 5 loop filter status.
074h STATUS.DPLL6_FILTER_STATUS DPLL 6 loop filter status.
07Ch STATUS.DPLL7_FILTER_STATUS DPLL 7 loop filter status.
084h STATUS.DPLL_SYS_FILTER_STATUS System DPLL loop filter status.
08Ah STATUS.USER_GPIO0_TO_7_STATUS User controlled GPIO level.
08Bh STATUS.USER_GPIO8_TO_15_STATUS User controlled GPIO level.
08Ch STATUS.IN0_MON_FREQ_STATUS Input 0 reference monitor frequency status and unit.
08Eh STATUS.IN1_MON_FREQ_STATUS Input 1 reference monitor frequency status and unit.
090h STATUS.IN2_MON_FREQ_STATUS Input 2 reference monitor frequency status and unit.
092h STATUS.IN3_MON_FREQ_STATUS Input 3 reference monitor frequency status and unit.
094h STATUS.IN4_MON_FREQ_STATUS Input 4 reference monitor frequency status and unit.
096h STATUS.IN5_MON_FREQ_STATUS Input 5 reference monitor frequency status and unit.
098h STATUS.IN6_MON_FREQ_STATUS Input 6 reference monitor frequency status and unit.
09Ah STATUS.IN7_MON_FREQ_STATUS Input 7 reference monitor frequency status and unit.
09Ch STATUS.IN8_MON_FREQ_STATUS Input 8 reference monitor frequency status and unit.
09Eh STATUS.IN9_MON_FREQ_STATUS Input 9 reference monitor frequency status and unit.
0A0h STATUS.IN10_MON_FREQ_STATUS Input 10 reference monitor frequency status and unit.
0A2h STATUS.IN11_MON_FREQ_STATUS Input 11 reference monitor frequency status and unit.
0A4h STATUS.IN12_MON_FREQ_STATUS Input 12 reference monitor frequency status and unit.
0A6h STATUS.IN13_MON_FREQ_STATUS Input 13 reference monitor frequency status and unit.
0A8h STATUS.IN14_MON_FREQ_STATUS Input 14 reference monitor frequency status and unit.
0AAh STATUS.IN15_MON_FREQ_STATUS Input 15 reference monitor frequency status and unit.
0ACh STATUS.OUTPUT_TDC_CFG_STATUS Output TDC global status.
0ADh STATUS.OUTPUT_TDC0_STATUS Output TDC 0 status.
0AEh STATUS.OUTPUT_TDC1_STATUS Output TDC 1 status.
0AFh STATUS.OUTPUT_TDC2_STATUS Output TDC 2 status.
0B0h STATUS.OUTPUT_TDC3_STATUS Output TDC 3 status.
0B4h STATUS.OUTPUT_TDC0_MEASUREMENT Output TDC 0 measurement status.
Table 24: STATUS Register Index
Offset
(Hex)
Register Module Base Address: C03Ch
Individual Register Name Register Description
