33©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
0BAh RESERVED This register must not be modified from the read value
0BBh RESERVED This register must not be modified from the read value
0C4h STATUS.OUTPUT_TDC1_MEASUREMENT Output TDC 1 measurement status.
0CAh RESERVED This register must not be modified from the read value
0CBh RESERVED This register must not be modified from the read value
0CCh STATUS.OUTPUT_TDC2_MEASUREMENT Output TDC 2 measurement status.
0D2h RESERVED This register must not be modified from the read value
0D3h RESERVED This register must not be modified from the read value
0D4h STATUS.OUTPUT_TDC3_MEASUREMENT Output TDC 3 measurement status.
0DAh RESERVED This register must not be modified from the read value
0DBh RESERVED This register must not be modified from the read value
0DCh STATUS.DPLL0_PHASE_STATUS Phase offset at output of decimator.
0E1h RESERVED This register must not be modified from the read value
0E2h RESERVED This register must not be modified from the read value
0E3h RESERVED This register must not be modified from the read value
0E4h STATUS.DPLL1_PHASE_STATUS Phase offset at output of decimator.
0E9h RESERVED This register must not be modified from the read value
0EAh RESERVED This register must not be modified from the read value
0EBh RESERVED This register must not be modified from the read value
0ECh STATUS.DPLL2_PHASE_STATUS Phase offset at output of decimator.
0F1h RESERVED This register must not be modified from the read value
0F2h RESERVED This register must not be modified from the read value
0F3h RESERVED This register must not be modified from the read value
0F4h STATUS.DPLL3_PHASE_STATUS Phase offset at output of decimator.
0F9h RESERVED This register must not be modified from the read value
0FAh RESERVED This register must not be modified from the read value
0FBh RESERVED This register must not be modified from the read value
0FCh STATUS.DPLL4_PHASE_STATUS Phase offset at output of decimator.
101h RESERVED This register must not be modified from the read value
102h RESERVED This register must not be modified from the read value
103h RESERVED This register must not be modified from the read value
104h STATUS.DPLL5_PHASE_STATUS Phase offset at output of decimator.
Table 24: STATUS Register Index
Offset
(Hex)
Register Module Base Address: C03Ch
Individual Register Name Register Description
To Next Page
