8A3xxxx Family Programming Guide
BYTE.OTP_EEPROM_PWM_BUFF_31
-
BYTE.OTP_EEPROM_PWM_BUFF_32
-
BYTE.OTP_EEPROM_PWM_BUFF_33
-
Table 431: BYTE.OTP_EEPROM_PWM_BUFF_31 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_31 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
01Fh DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_31 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 432: BYTE.OTP_EEPROM_PWM_BUFF_32 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_32 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
020h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_32 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 433: BYTE.OTP_EEPROM_PWM_BUFF_33 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_33 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
021h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_33 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
