BYTE.OTP_EEPROM_PWM_BUFF_19
-
BYTE.OTP_EEPROM_PWM_BUFF_20
-
BYTE.OTP_EEPROM_PWM_BUFF_21
-
Table 419: BYTE.OTP_EEPROM_PWM_BUFF_19 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_19 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
013h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_19 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 420: BYTE.OTP_EEPROM_PWM_BUFF_20 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_20 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
014h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_20 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
Table 421: BYTE.OTP_EEPROM_PWM_BUFF_21 Bit Field Locations and Descriptions
Offset
Address
(Hex)
BYTE.OTP_EEPROM_PWM_BUFF_21 Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
015h DATA[7:0]
BYTE.OTP_EEPROM_PWM_BUFF_21 Bit Field Descriptions
Bit Field Name Field Type Default Value Description
DATA[7:0] R/W 0 Data to be transferred into OTP, EEPROM or PWM.
