IDT 8A3 Series - STATUS.DPLL2_REF_STAT

63©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
STATUS.DPLL2_REF_STAT
Indicates which reference is currently selected for tracking.
STATUS.DPLL1_REF_STAT Bit Field Descriptions
Bit Field Name Field Type Default Value Description
RESERVED N/A - This field must not be modified from the read value
DPLL1_INPUT[4:0] R/O 0 Current reference input for DPLL 1.
0x00 = CLK0
0x01 = CLK1
0x02 = CLK2
0x03 = CLK3
0x04 = CLK4
0x05 = CLK5
0x06 = CLK6
0x07 = CLK7
0x08 = CLK8
0x09 = CLK9
0x0A = CLK10
0x0B = CLK11
0x0C = CLK12
0x0D = CLK13
0x0E = CLK14
0x0F = CLK15
0x10 = write-phase input
0x11 = write-frequency input
0x12 = XO_DPLL
0x1F = no reference
Table 60: STATUS.DPLL2_REF_STAT Bit Field Locations and Descriptions
Offset
Address
(Hex)
STATUS.DPLL2_REF_STAT Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
024h RESERVED[7:5] DPLL2_INPUT[4:0]
