iTero Element 2 and iTero Element Flex User Manual

4.7.1 Clearance tool

You can view the occlusal clearance between opposing teeth in the Viewer.

In the Viewer, tap .

The clearance between the opposing teeth is displayed.

Figure 101: Clearance tool and legend displayed in the Viewer

The occlusal clearance can also be viewed from View mode while scanning the patient, as described in

section 4.3.3.
