iTero Element 2 - Viewing the Rx; Figure 108: Patients Profile Page - View Rx Option; Figure 109: Rx Details Window

To Next Page

To Previous Page

iTero Element 2 and iTero Element Flex User Manual

5.4 Viewing the Rx

If required, you can view the Rx of a previous order.

To view the Rx of a previous order:

In the patient’s profile page, select the order for which to view the Rx and then click View Rx.

Figure 108: Patient’s profile page – View Rx option

The Rx Details window is displayed.

Figure 109: Rx Details window

Tap to return to the patient’s profile page.
