iTero Element 2 and iTero Element Flex User Manual

3.6 Defining the scanner settings

The scanner settings enable you to define your preferences and the settings that are displayed by default when

you use the scanner.

To define the scanner settings:

Click the button.

The Settings window is displayed.

Figure 38: Settings window

Tap the settings you would like to define.

o Computer settings, described in section 3.6.1

o User settings, defined in section 3.6.2

o System settings, defined in section 3.6.3

The relevant window opens.

Make your changes and then tap to save your changes and return to the Settings window.
