iTero Element 2 and iTero Element Flex User Manual

If you do not want to connect to the network automatically, tap the network you are connected to and then

tap Forget.

You will need to select the required network and enter the Wi-Fi password the next time you want to

connect.

Figure 43: Forgetting or Disconnecting from the network

To disconnect from the network, click Disconnect.

Tap to save your settings and return to the Settings window.
