4.3 Viewing the scan
After scanning the patient, click to move to View mode to inspect the model and ensure that sufficient
occlusal and buccal anatomy has been captured, and that the model is accurate and complete.
If there are missing scan segments or missing bites, a message will be displayed at the beginning of the
post-processing stage notifying you of this and enabling you to go back and fix the scan. For more information,
see section 4.3.1.
While viewing the scan, you can:
Delete selected areas of a scan, as described in section 4.3.2
Trim excess tissues from the scan, as described in 4.3.4
Manually create the die separation if the green hint point was not on the center of the prepped tooth during
scanning, as described in section 4.3.5
After you have reviewed the scan, tap on the toolbar to send the scan to the lab or to storage, as described
in section 4.4.
4.3.1 Missing scan segment notifications
If there are missing scan segments or bite scans when you tap the button, you will be notified at the
beginning of the post-processing stage, and you will be able to go back and fix the scan, in order to reduce
manual intervention later on.
Notifications will be displayed in the following cases:
Missing prep or arch – segments were not scanned or not stitched together properly
Bite issues:
o Missing bite
o Bite scanned from one side only
o Discrepancy between the left and the right bite scans
In addition, the bite section in the navigation controls will be highlighted in red.
