iTero Element 2 and iTero Element Flex User Manual

Drag the loupe onto the model to view areas of interest and potential treatment areas in the animation

window.

An animation is displayed, comparing the state of the teeth in the current area of interest on the selected

scan dates.

Figure 114: Area of interest from the first scan displayed in the animation window

Figure 115: Area of interest from the second scan displayed in the animation window
