iTero Element 2 and iTero Element Flex User Manual

1.4 iTero Element hardware

The following iTero scanner models are described below:

 iTero Element 2

o Wheel-stand configuration

o Counter-stand configuration

 iTero Element Flex

o Laptop configuration (available in selected countries only)

Refer to http://www.itero.com/en/products/itero_element_flex for the minimum system requirements.

1.4.1 iTero Element 2

Front view

A Touch screen

B Power switch

C Power LED

D Wand

E Cradle

F Wheel base

Figure 1: Front view of the iTero Element 2
