iTero Element 2 and iTero Element Flex User Manual

5.3 Creating a new scan for a specific patient

If required, you can create a new scan for a specific patient. The Rx will be opened with the patient’s details

already filled in.

To create a new scan for a specific patient:

In the patient’s profile page, tap New Scan.

Figure 106: Patient’s profile page – New Scan option

The New Scan window is displayed.

Figure 107: New Scan window with patient’s details already filled in

Fill in the rest of the Rx details according to the new requirements.
