iTero Element 2 - Figure 46: Only Scanning Range Is Highlighted

To Next Page

To Previous Page

iTero Element 2 and iTero Element Flex User Manual

Scan setting

Scan options

Highlight

recommended

scanning range

check box

Select this check box to highlight only the scanning range on the

navigation controls.

Figure 46: Only scanning range is highlighted

Additional Scan

Feedback

Select the relevant check boxes to display areas of missing anatomy

while scanning, as described in section 4.2.3.1.

 Orthodontic

 Restorative

Tap to save your changes, and return to the Settings window.
