iTero Element 2 and iTero Element Flex User Manual

3.6.1.3 Defining the Wi-Fi settings

The first time you connect your scanner to the clinic’s Wi-Fi network, you will need to add your password. After

that, by default, the scanner will connect automatically.

To connect to the Wi-Fi network:

Tap the Wi-Fi button.

A list of nearby Wi-Fi networks is displayed.

Figure 41: List of nearby Wi-Fi networks

Select your clinic network and click Connect.

Enter your network security key (password) in the window that opens and then click Connect.

Figure 42: Connecting to the clinic Wi-Fi network

The scanner will connect to the Wi-Fi network, and the status changes to Connected.
