iTero Element 2 and iTero Element Flex User Manual

With your finger, mark the area you would like to trim away.

Figure 85: Mark the area to be trimmed away

The area to be trimmed away is highlighted and the confirmation icon is enabled.

Figure 86: Selected area highlighted and the confirmation icon enabled

If required, you can tap to undo the trimming
