iTero Element 2 and iTero Element Flex User Manual

To view or review orders:

Tap the Orders button on the home screen.

The Orders page is displayed, showing two panes – In Progress orders and Past Orders.

o In Progress: Scans have not yet been submitted.

o Past Orders: Scans have already been submitted.

Tap on an order in the In Progress pane to view the following options:

Figure 118: In Progress pane – options

o View Rx: Opens the Rx Details window, enabling you to view the prescription for this order.

o Scan: Opens the Scan window, enabling you to create a new scan or continue scanning the patient.

o View Scans: Opens the View window, enabling you to review the current scan.
