Johnson Controls VS3 Series User Manual

193
Appendix A—Description of parameters
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Code Modbus ID Parameter Application RO/RW
P11.1.5 518 Interval 1 To Day 2,3 RW
Use this parameter to set the day of week for Interval function to stop on.
0 = Sunday
1 = Monday
2 = Tuesday
3 = Wednesday
4 = Thursday
5 = Friday
6 = Saturday
P11.1.6 519 Interval 1 Channel 2,3 RW
Use this parameter to assign the interval to a select time channel to store the interval time.
0 = Not used
1 = Time channel 1
2 = Time channel 2
3 = Time channel 3
P11.2.1 2488 Interval 2 Setting 2,3 RW
Use this parameter with the Interval time setting for interval 2 to set the desired time frame for the
selection; to be Weekly or Daily.
0 - Weekly - would setup the timer for the week long. Drive starts on the on day/time and runs to the
stop day and time.
1 - Daily - would setup the timer for the defined day. Drive starts on time and stops on that day off time,
for the listed days in the sequence
P11.2.2 495 Interval 2 On Time 2,3 RW
Use this parameter to set the on time for Interval function. It uses 24-hour format. Use to specify a time
of day for a desired function to be disabled.
P11.2.3 497 Interval 2 Off Time 2,3 RW
Use this parameter to set the off time for Interval function. It uses 24-hour format. Use to specify a time
of day for a desired function to be disabled.
P11.2.4 520 Interval 2 From Day 2,3 RW
Use this parameter to set the day of week for Interval function to start on.
0 = Sunday
1 = Monday
2 = Tuesday
3 = Wednesday
4 = Thursday
5 = Friday
6 = Saturday
P11.2.5 521 Interval 2 To Day 2,3 RW
Use this parameter to set the day of week for Interval function to stop on.
0 = Sunday
1 = Monday
2 = Tuesday
3 = Wednesday
4 = Thursday
5 = Friday
6 = Saturday
P11.2.6 522 Interval 2 Channel 2,3 RW
Use this parameter to assign the interval to a select time channel to store the interval time.
0 = Not used
1 = Time channel 1
2 = Time channel 2
3 = Time channel 3
P11.3.1 2489 Interval 3 Setting 2,3 RW
Use this parameter with the Interval time setting for interval 3 to set the desired time frame for the
selection; to be Weekly or Daily.
0 - Weekly - would setup the timer for the week long. Drive starts on the on day/time and runs to the
stop day and time.
1 - Daily - would setup the timer for the defined day. Drive starts on time and stops on that day off time,
for the listed days in the sequence
P11.3.2 499 Interval 3 On Time 2,3 RW
Use this parameter to set the on time for Interval function. It uses 24-hour format. Use to specify a time
of day for a desired function to be disabled.
