Johnson Controls VS3 Series User Manual

201
Appendix A—Description of parameters
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Code Modbus ID Parameter Application RO/RW
P12.4.3.3 1735 BACnet IP BBMD IP 1,2,3 RW
The IP address of the BACnet IP Broadcast Management Device.
P12.4.3.4 1737 BACnet IP BBMD Port 1,2,3 RW
The BBMD Port number.
P12.4.3.5 1738 BACnet IP Registration Interval 1,2,3 RW
The registration interval to keep a live connection to the BBMD. Unit is seconds.
P12.4.3.6 1739 BACnet IP Comm Timeout 1,2,3 RW
Defines the number of seconds after a timeout is indicated after a communication break or disconnected
EtherNet link. Value 0 disables communication link supervision.
P12.4.3.7 1740 BACnet IP Protocol Status 1,2,3 RO
Fieldbus Protocol Status tells the status of the protocol.
P12.4.3.8 1741 BACnet IP Fault Behavior 1,2,3 RW
Defines when Fieldbus fault to be raise if fault condition is detected.
P12.4.3.9 1742 BACnetIP Instance Number 1,2,3 RW
The Device Object’s Instance number is used in conjunction with the MAC address to assign the devices
on the network. The instance number can have up to 127 nodes on it before a different instance number
is required.
P13.1.1 340 Language 1,2,3 RW
Use this parameter to allow to control the frequency converter through the keypad in the language of
your choice.
P13.1.2 142 Application 1,2,3 RW
Use this parameter to set the active application marco to use.
P13.1.3 619 Parameter Sets 1,2,3 RW
Use this parameter to reload the factory default parameter values, and to store and load two customized
parameter sets.
0 = No
1 = Reload Default
2 = Reload Set #1
3 = Reload Set #2;
4 = Store Set #1;
5 = Store Set #2;
6 = Reset;
7 = Reload Defaults VM
P13.1.4 620 Up To Keypad 1,2,3 RW
Use this parameter to enable uploading all parameter to the keypad.
0 = No
1 = Yes (All parameters)
P13.1.5 621 Down From Keypad 1,2,3 RW
Use this parameter to enable downloading parameter from the keypad.
0 = No
1 = All parameters
2 = All Parameter, No Motor
3 = App Parameter
P13.1.6 623 Parameter Comparison 1,2,3 RW
Use this parameter to initiate a Parameter Comparison function, you can compare the actual parameter
values to the values of your customized parameter sets and those loaded to the control keypad.
The actual parameter values are first compared to those of the customized parameter Set1. If no
differences are detected, a “0” is displayed on the lowermost line of the keypad.
If any of the parameter values differ from those of the Set1 parameters, the number of the deviations is
displayed together.
By pressing the right arrow button once again you will see both the actual value and the value it was
compared to. In this display, the value on the Description line (in the middle) is the default value, and the
one on the value line (lowermost line) is the edited value. You can also edit the actual value by pushing
the Right Arrow button.
Actual values can also be compared to Set2, Factory Settings and Keypad Set values.
