203
Appendix A—Description of parameters
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Code Modbus ID Parameter Application RO/RW
P13.1.17 626 Startup Wizard 1,2,3 RW
The Startup Wizard facilitates commissioning the drive. If selected Enable, the Startup Wizard prompts
operator for the language and application desired, RTC time clock and then advances through the start-
up parameter list/Application Mini wizard in keypad. After completion it allows the user to go to the
Main menu or default page and this parameter is set to Disabled. The Startup Wizard is always enabled
for the initial power up of the VFD. By setting this parameter to Disable without going through the
Startup Wizard it will disable it from being active on Start up. If user goes into Start Up Wizard after
completion or defaults drive the Startup wizard will be Enabled.
0 = Enabled
1 = Disabled
P13.1.18 2412 Jog Softkey Hidden 1,2,3 RW
Use this parameter to hidd the jog function from the soft key buttons.
0 = Disable
1 = Enable
P13.1.19 2413 Reverse Softkey Hidden 1,2,3 RW
Use this parameter to hide the Reverse fuction from the soft key buttons.
0 = Disable
1 = Enable
P13.1.20 2424 Output Display Unit 1,2,3 RW
This parameter allows for selecting a desired unit and scaled output to be viewed in the monitor
menu as user output and refernece display. Value is scaled based on the max value setting the min
and max value.
0 = %
1 = 1/min
2 = rpm
3 = ppm
4 = pps
5 = l/s
6 = l/min
7 = l/h
8 = kg/s
9 = kg/min
10 = kg/h
11 = m3/s
12 = m3/min
13 = m3/h
14 = m/s
15 = mbar
16 = bar
17 = Pa
18 = kPa
19 = mVs
20 = kW
21 = deg C
22 = GPM
23 = gal/s
24 = gal/min
25 = gal/h
26 = lb/s
27 = lb/min
28 = lb/h
29 = CFM
30 = ft3/s
31 = ft3/min
32 = ft3/h
33 = ft/s
34 = in wg
35 = ft wg
36 = PSI
37 = lb/in2
38 = HP
39 = deg F
40 = PA
41 = WC
42 = HG
43 = ft
44 = m
45 = Hz
46 = Strokes/min
