Appendix A—Description of parameters
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Code Modbus ID Parameter Application RO/RW
P13.1.21 2460 Output Display Unit Min 1,2,3 RW
Use this parameter to set the minimum scaled value when changing the display unit to a value other than
the default Hz.
P13.1.22 2425 Output Display Unit Max 1,2,3 RW
Use this parameter to set the maximum scaled value when changing the display unit to a value other
than the default Hz.
P13.2.1 640 Keypad Software Version 1,2,3 RO
Keypad firmware Version
P13.2.2 642 Motor Control Software Version 1,2,3 RO
DSP/Motor Control Software Version
P13.2.3 644 Application Software Version 1,2,3 RO
MCU/Application Software Version
P13.2.4 1714 Software Bundle Version 1,2,3 RO
Software bundle version number, this encompasses the keypad software, Motor control software and
application software.
P13.3.1 646 Brake Chopper 1,2,3 RW
This parameter is used to provide a status to indicate if the unit has a brake chopper installed in it.
P13.3.2 647 Brake Resistor Status 1,2,3 RO
The Hardware information - indication of the Brake Resistor status being connected or disconnect.
P13.3.3 648 Serial Number 1,2,3 RO
Serial Number of the drive.
P13.4.1 566 Real Time Clock 1,2,3 RW
This parameter provides the ability to see and adjust the time clock settings in the drive. Formatted in
MM.DD.YY, HH:MM:SS.
P13.4.2 582 Daylight Saving 1,2,3 RW
This parameter provides the ability to see and adjust the daylight saving time rule.
0 = Off
1 = EU
2 = US
P13.4.3 601 Total MWh Count 1,2,3 RO
Energy Consumption MWH Meter (not resettable)
P13.4.4 603 Total Power Day Count 1,2,3 RO
Total Time Power is on, Days count (not resettable)
P13.4.5 606 Total Power Hr Count 1,2,3 RO
Total time Power is on, Hr Count (not resettable)
P13.4.6 604 Trip MWh Count 1,2,3 RO
Entergy Consumption MWH Meter(resettable)
P13.4.7 635 Clear Trip MWh Count 1,2,3 RW
This parameter will reset the Trip MWh count.
P13.4.8 636 Trip Power Day Count 1,2,3 RO
Total Time Power is On, Days count (resettable)
P13.4.9 637 Trip Power Hr Count 1,2,3 RO
Total time Power is on, Hr Count (resettable)
P13.4.10 639 Clear Trip Power Count 1,2,3 RW
Resets the Trip Power Counter
M1.1 1 Output Frequency RO
Instantaneous output frequency going to the motor in Hz.
