Table 5-6
SENSe command summary
Command Description
Default
parameter
SCPI
[:SENSe[1]]
:FUNCtion <name>
:FUNCtion?
:DATA?
:DATA
:FRESh?
:HOLD
:WINDow <NRf>
:WINDow?
:COUNt <NRf>
:COUNt?
:STATe <b>
:STATe?
Select measurement function: ‘VOLTage:AC’, ‘VOLTage
:DC’, RESistance’, ‘FRESistance’, ‘CURRent:AC’,
‘CURRent: DC’, ‘FREQuency’, ‘TEMPerature’,
‘PERiod’, ‘DIODe’, “CONTinuity’.
Query function.
Return the last instrument reading.
Returns a new (fresh) reading.
Path to control Hold feature:
Set Hold window (%); 0.01 to 20.
Query Hold window.
Set Hold count; 2 to 100.
Query Hold count.
Enable or disable Hold.
Query state of Hold.
‘VOLT[:DC]’
1
5
OFF
√
√
√
√
:CURRent:AC
:NPLCycles <n>
:NPLCycles?
:RANGe
[:UPPer] <n>
[:UPPer]?
:AUTO <b>
:AUTO?
:REFerence <n>
:STATe <b>
:STATe?
:ACQuire
:REFerence?
:DIGits <n>
:DIGits?
:AVERage
:TCONtrol <name>
:TCONtrol?
:COUNt <n>
:COUNt?
:STATe <b>
:STATe?
:DETector
:BANDwidth <NRf>
:BANDwidth?
Path to configure AC current.
Set integration rate (line cycles; 0.01 to 10).
Query line cycle integration rate.
Path to configure measurement range:
Select range (0 to 3.1).
Query range.
Enable or disable auto range.
Query auto range.
Specify reference (-3.1 to 3.1).
Enable or disable reference.
Query state of reference.
Use input signal as reference.
Query reference value.
Specify measurement resolution (4 to 7).
Query resolution.
Path to configure and control the filter.
Select filter type: (MOVing or REPeat).
Query filter type.
Specify filter count (1 to 100).
Query filter count.
Enable or disable filter.
Query state of digital filter.
Path to configure bandwidth:
Specify bandwidth (3 to 300e3).
Query bandwidth.
1
3
ON
0
OFF
6
(Note)
10
OFF
30
√
√
√
√
√
√
√
√
√
√
√
√
5-10 SCPI Command Reference
