Keithley 2010 User Manual

For the ohms function, the selected range depends on the Firmware Revision of the
Model 2010. The firmware revision is displayed during power-up. Example display message for
A12 firmware:
REV A12 A02
Table D-2 summarizes ohms ranges for various firmware revision levels.
Table D-2
Range selection for ohms function
Model 2010 Firmware Revision
Range Command
for Ohms* A0 through A9 A10 and A11 A12 and higher
R0
R1
R2
R3
R4
R5
R6
R7
R8
Auto
100Ω
1kΩ
10kΩ
100kΩ
1MΩ
10MΩ
10MΩ
???
Auto
1kΩ
10kΩ
100kΩ
1MΩ
10MΩ
100MΩ
100MΩ
???
Auto
100Ω
1kΩ
10kΩ
100kΩ
1MΩ
10MΩ
10MΩ
100MΩ
*2-wire and 4-wire ohms.
D-6 Models 196/199 Commands

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
