Model 2700 Multimeter/Switch System User’s Manual Basic DMM Operation 3-49
Remote programming for basic measurements
Basic measurement commands
NOTE When measurements are performed, the readings are fed to other enabled
processing operations.
Appendix D explains “Data flow (remote operation)”
and the commands used to return the various processed readings.
Commands to perform basic measurements are listed in Table 3-7.
Table 3-7
Basic measurement commands
Commands
1
Description Default Ref
Select measurement function
[SENSe[1]] Optional root command.
:FUNCtion <name> [, <clist>] Select measurement function:
<name> = ‘VOLTage[:DC]’,
‘VOLTage:AC’, ‘CURRent[:DC]’,
‘CURRent:AC’, ‘RESistance’,
‘FRESistance’, ‘CONTinuity’,
‘FREQuency’, or ‘PERiod’.
Note: [:DC] is optional.
VOLT a
DCV function
[SENSe[1]] Optional root command.
:VOLTage[:DC]:IDIVider <b> Enable/disable DCV input divider;
<b> = ON or OFF.
OFF
Ω4 function
[SENSe[1]] Optional root command.
:FRESistance:OCOMpensated <b>
[, <clist>]
Enable/disable offset-compensated ohms. OFF b
SYSTem Root command for SYSTem subsystem.
:FRESistance:TYPEx, <name> Select 4-wire ohms mode;
<name> = NORMal or CSIDe.
x = Slot number (1 or 2).
NORM

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
