B-10 Model 7700 Connection Guide Model 2700 Multimeter/Switch System User’s Manual
Figure B-9
Voltage connections (DC or AC)
Connection log
Make a copy of Table B-1 and affix it to the cover of the Model 7700. Use this to record
connection information and channel descriptions as needed.
Channel 1
HI
LO
Channel 20
HI
LO
(Channels 2-19)
+
+
DC Voltage AC Voltage

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
