4-6 Range, Digits, Rate, Bandwidth, and Filter Model 2700 Multimeter/Switch System User’s Manual
Scanning
When a simple scan is configured, the present digits setting will apply to all channels in
the scan. When an advanced scan is configured, each channel can have its own unique
digits setting. Details to configure and run a scan are provided in
Section 7.
For remote programming, the <clist> parameter is used to configure channels for a scan.
Remote programming — digits
Digits commands
The commands to control display resolution (digits) are listed in Table 4-3. Additional
information on these commands follow the table.
NOTE Query commands are not included in Table 4-3. All commands for the SENSe
subsystem are provided in Table 15-5.
Table 4-3
Digits commands
Commands* Description Default
[SENSe[1]] Optional root command.
:VOLTage[:DC]:DIGits <n> [, <clist>] Set # of digits for DCV; <n> = 4 to 7. 7
:VOLTage:AC:DIGits <n> [, <clist>] Set # of digits for ACV; <n> = 4 to 7. 6
:CURRent[:DC]:DIGits <n> [, <clist>] Set # of digits for DC1; <n> = 4 to 7. 7
:CURRent:AC:DIGits <n> [, <clist>] Set # of digits for ACI; <n> = 4 to 7. 6
:RESistance:DIGits <n> [, <clist>] Set # of digits for Ω2; <n> = 4 to 7. 7
:FRESistance:DIGits <n> [, <clist>] Set # of digits for Ω4; <n> = 4 to 7. 7
:TEMPerature:DIGits <n> [, <clist>] Set # of digits for TEMP; <n> = 4 to 7. 6
:FREQuency:DIGits <n> [, <clist>] Set # of digits for FREQ; <n> = 4 to 7. 7
:PERiod:DIGits <n> [, <clist>] Set # of digits for PERIOD; <n> = 4 to 7. 7
Channel list parameter:
<clist> = (@SCH)
where: S = Mainframe slot number (1 or 2)
CH = Switching module channel number (must be 2 digits)
Examples: (@101) = Slot 1, Channel 1
(@101, 203) = Slot 1, Channel 1 and Slot 2, Channel 3
(@101:110) = Slot 1, Channels 1 through 10
*The <clist> parameter is used to configure one or more channels for a scan. Each channel in the <clist> must be set to the function
specified by the digits command. If not, a conflict error (-221) will occur. For example, VOLTage:AC:DIGits 4.5, (@101) is only
valid if scan channel 101 is set for the ACV function.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
