Model 2700 Multimeter/Switch System User’s Manual SCPI Reference Tables 15-9
Table 15-5
SENSe command summary
Command Description
Default
parameter Ref SCPI
[SENSe[1]]
:FUNCtion <name>
[, <clist>]
Select function: ‘VOLTage[:DC]’,
‘VOLTage :AC’, ‘CURRent[:DC]’,
‘CURRent:AC’, ‘RESistance’,
‘FRESistance’, ‘TEMPerature’,
‘FREQuency’, ‘PERiod’, ‘CONTinuity’.
VOLT:DC Sec 3 ✓
:FUNCtion? [<clist>] Query function. ✓
:DATA[:LATest]? Return the last reading. Sec 3 ✓
:DATA:FRESh? Return the last “fresh” reading. Sec 3
:HOLD Path to control Hold feature: Sec 8
:WINDow <NRf> Set Hold window in % (0.01 to 20). 1
:WINDow? Query Hold window.
:COUNt <NRf> Set Hold count; 2 to 100. 5
:COUNt? Query Hold count.
:STATe <NRf> Enable or disable Hold. OFF
:STATe? Query state of Hold.
:CAVerage <b> [, <clist>] Channel average calculation: Sec 5
:DELay <NRf> [, <clist>] Set delay between the two measurements
in seconds (0 to 99999.999).
1
0.5
:DELay? [<clist>] Query delay.
[:STATe] <b> [, <clist>] Enable or disable channel average. OFF
[:STATe]? [, <clist>] Query state of channel average.
:RATio <b> [, <clist>] Channel ratio calculation: OFF Sec 5
:DELay <NRf> [, <clist>] Set delay between the two measurements
in seconds (0 to 99999.999).
1
0.5
:DELay? [<clist>] Query delay.
[:STATe] <b> [, <clist>] Enable or disable channel ratio. OFF
[:STATe]? [, <clist>] Query state of channel ratio.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
