15-10 SCPI Reference Tables Model 2700 Multimeter/Switch System User’s Manual
[SENSe[1]]
:VOLTage[:DC] Path to configure DC voltage. Sec 3 ✓
:APERture <n> [, <clist>] Set integration rate in seconds (60Hz;
1.67e-4 to 1, 50Hz; 2e-4 to 1).
(Note 2) Sec 4
:APERture? [<clist>] Query aperture integration rate.
:NPLCycles <n> [, <clist>] Set integration rate in line cycles (60Hz;
0.01 to 60, 50Hz; 0.01 to 50).
5.0 Sec 4 ✓
:NPLCycles? [<clist>] Query line cycle integration rate. ✓
:RANGe Path to set measurement range: Sec 4 ✓
[:UPPer] <n> [, <clist>] Select range (0 to 1010). 1000 ✓
[:UPPer]? [<clist>] Query range. ✓
:AUTO <b> [, <clist>] Enable or disable auto range. ON ✓
:AUTO? [<clist>] Query state of auto range. ✓
:DIGits <n> [, <clist>] Specify measurement resolution (4 to 7). 7 Sec 4
:DIGits? [<clist>] Query resolution.
:REFerence <n> [, <clist>] Specify reference (-1010 to 1010). 0 Sec 5 ✓
:STATe <b> [, <clist>] Enable or disable reference. OFF ✓
:STATe? [<clist>] Query state of reference. ✓
:ACQuire [, <clist>] Use input signal as reference.
:REFerence? [<clist>] Query reference value. ✓
:AVERage Path to configure and control filter: Sec 4
:TCONtrol <name> Select filter type: (MOVing or REPeat). (Note 3)
:TCONtrol? Query filter type.
:WINDow <NRf> Set filter window in % of range
(0 to 10).
0.1
:WINDow? Query filter window.
:COUNt <n> [, <clist>] Specify filter count (1 to 100). 10
:COUNt? [<clist>] Query filter count.
[:STATe] <b> [, <clist>] Enable or disable filter. (Note 4)
[:STATe]? [<clist>] Query state of digital filter.
:IDIVider <b> Enable or disable 10MΩ input divider. OFF Sec 3
:IDIVider? Query state of input divider.
Table 15-5 (continued)
SENSe command summary
Command Description
Default
parameter Ref SCPI

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
